Precision Coil Winding for Audio

Orthocyclic precision and ECCA wire handling for voice coils, pickup windings, and audio transformers requiring acoustic linearity and minimal distortion.

Talk to an Engineer View Products
Audio

Industry Snapshot

Typical Materials

  • Copper magnet wire
  • ECCA (copper-clad aluminum)
  • Ultra-fine enameled copper
  • Voice coil formers

Common Applications

  • Loudspeaker voice coils
  • Headphone transducers
  • Guitar pickups
  • Audio transformers

Quality Standards

  • ISO 9001:2015
  • NIST-Traceable Calibration

Key Requirements

  • Orthocyclic winding for linearity
  • ECCA wire compatible
  • Ultra-fine wire handling
  • Bifilar capability
0.02mm
Ultra-Fine Wire
Headphone transducers
AWG 58
Fine Gauge Range
Voice coil precision
ECCA
Wire Compatible
Reduced moving mass

Recommended Machines

These machines are most commonly specified for this industry

1201 Series Bobbin Winder

1201 Series Bobbin Winder

Precision Benchtop Bobbin Winder

$3,695.00
Ships in 2-4 weeks
RPM 0-5000 (varies by model)
AWG 10-56
Traverse Manual
View DetailsSpecs
1260 Series Automatic Winder

1260 Series Automatic Winder

Heavy-Duty Automatic Winding System

$21,995.00
Ships in 2-4 weeks
RPM 0-2600 (varies by model)
AWG 5-15
Traverse 24"
View DetailsSpecs
1250 Series Automatic Winder

1250 Series Automatic Winder

Programmable Automatic Coil Winding System

From $8,995.00
Ships in 2-4 weeks
RPM 0-5000 (varies by model)
AWG 10-56
Traverse 7" (S) / 14" (L)
View DetailsSpecs
View All Machines

Need Industry-Specific Modifications?

We build custom fixtures, tooling, and machine modifications tailored to your industry's unique requirements.

Discuss Your Application

Precision Repeatability

±0.001" positioning accuracy ensures consistent coils across production runs.

Full Traceability

NIST-traceable calibration and complete documentation packages for audits.

Direct Engineering Support

Talk to the people who built your machine—no call centers, no scripts.

Made in USA

All machines built in our Moorpark, CA facility since 1976.

Frequently Asked Questions

What makes your machines suitable for audio transformer winding?

Our orthocyclic winding capability ensures consistent layer patterns critical for acoustic linearity and low distortion. Precise tension control prevents wire stretching that affects inductance, and programmable parameters ensure repeatable results across production runs.

Can you wind voice coils and guitar pickups?

Yes. We handle ultra-fine wire down to 0.02mm for voice coils, and support ECCA (enamel-coated copper-clad aluminum) wire commonly used in speaker applications. Our machines provide the consistent winding patterns essential for balanced tone and output in guitar pickups.

What types of coils can your machines wind?

Our machines handle transformers (power, audio, pulse, isolation), inductors, chokes, solenoids, motor coils, voice coils, sensor coils, and specialty windings. Capacities range from 10 mW to 10 kVA with programmable tension, speed, and layering patterns for orthocyclic, variable pitch, and multi-section winding.

What are your lead times?

Standard machines typically ship in 2-4 weeks. Custom configurations and special tooling may require 4-6 weeks. U.S.-based manufacturing means no overseas supply chain delays—we maintain inventory of common components to expedite orders when possible.

Do you provide custom tooling for unique bobbins?

Yes, we offer full in-house design, CAD modeling, simulation, and rapid prototyping. Our engineering team works directly with you to develop custom arbors, fixtures, and tooling for any bobbin geometry. Typical turnaround is 2-3 weeks for custom tooling.

Ready to Discuss Your Application?

Talk to an engineer about your specific requirements and get a custom quote.

Talk to us now
ISO 9001
Certified Quality
NIST Traceable
Calibration Standards
Made in USA
Since 1976
1-Year Warranty
Parts & Labor
